Mobile Vehicle Disinfection System for Farms

• Modular Vehicle Disinfection: The spray arch, lower treatment system, pump and dosing components can be configured as an integrated vehicle biosecurity station.
• Mobile Project Configuration: Modular components support flexible deployment, relocation and site-specific installation.
• Automatic Vehicle Detection: Vehicle sensors can activate the programmed spray cycle when a vehicle enters the treatment zone.
• Multi-Direction Spray Coverage: Side, upper and lower spray lines can be arranged to target vehicle surfaces, wheels and chassis.
• Controlled Chemical Dosing: The dosing system can be configured for the selected compatible disinfectant.
• Wheel and Chassis Treatment: Lower spray nozzles help reach wheel and underbody areas that are difficult to treat manually.
• Corrosion-Resistant Structure: Galvanized steel and stainless-steel components can be selected for demanding agricultural environments.
• Modular Assembly: Structural sections and spray components can be designed for practical installation and maintenance.
• Manual Override: Manual operation can be incorporated for testing, commissioning and maintenance.
• Commercial Farm Application: Suitable for feed trucks, livestock transporters, agricultural machinery, service vehicles and authorized farm traffic.
• Project-Specific Engineering: Vehicle clearance, spray arrangement, pump performance and control functions are available according to project requirements.

• Disinfection Arch: Structural frame supporting the main vehicle spray lines.
• Lower Spray Assembly: Spray lines positioned near the vehicle path for wheel and chassis treatment.
• Spray Nozzles: Nozzles are arranged according to required spray coverage and vehicle dimensions.
• High-Pressure Pump Module: Provides the required pressure and flow for the configured spray system.
• Chemical Dosing Unit: Introduces the selected disinfectant into the spray circuit at the required dosing rate.
• Filtration System: Helps protect the pump and spray nozzles from particles in the liquid circuit.
• Vehicle Detection Sensors: Detect vehicle movement and initiate the automatic operating sequence.
• Control Cabinet: Manages automatic activation, manual operation and spray-cycle control.
• Connection Piping: Stainless-steel or suitable chemical-resistant piping connects the pump and spray assemblies.
• Drive-Through Platform: Provides a defined vehicle passage and can incorporate lower spray components.
• Optional Collection System: Drainage and wastewater collection can be incorporated according to project requirements.

Exact dimensions, pressure, flow rate, nozzle quantity, electrical supply, tank capacity and structural load should be confirmed according to the final vehicle fleet, farm layout and engineering design.

• Commercial Pig Farms: Vehicle disinfection for feed delivery, livestock transport, waste collection and service vehicles.
• Poultry Farms: Vehicle treatment at entrances to poultry houses, production complexes and controlled access zones.
• Cattle and Breeding Farms: Suitable for livestock transport and agricultural service vehicles.
• Feed Mills: Can be installed at vehicle entry points connecting feed production and farm logistics areas.
• Livestock Transport Facilities: Provides a defined sanitation stage for vehicles moving between controlled areas.
• Abattoirs and Processing Facilities: Suitable for vehicle hygiene procedures at controlled entrances.
• Farm Expansion Projects: Can be incorporated into new farm roads, gates, drainage and biosecurity infrastructure.
• Existing Farm Upgrades: Modular construction allows adaptation to established vehicle entrances.
• Agricultural Engineering Projects: Suitable for engineering contractors, distributors, agents and farm development projects.

• Arch Width and Height: Designed according to the largest vehicle using the entrance.
• Spray Coverage: Nozzle quantity, position, height and angle can be configured according to required coverage.
• Wheel and Chassis Treatment: Lower spray lines can be adapted to vehicle wheelbase and ground clearance.
• Pump Configuration: Pump pressure and flow can be selected according to the spray system.
• Chemical Dosing: Dosing equipment can be configured for the selected compatible disinfectant.
• Control System: Automatic sensor activation, manual override and cycle timing can be configured.
• Structural Material: Galvanized steel, stainless steel and other suitable materials are available according to climate and chemical conditions.
• Drainage: Wastewater collection and drainage connections can be coordinated with the farm wastewater system.
• Pre-Washing: A separate high-pressure washing stage can be incorporated where required.
• Traffic Configuration: Single-direction or two-way vehicle movement can be accommodated according to the site layout.
• OEM / ODM: Equipment configuration, labeling, packaging and documentation can be customized for distributors and engineering projects.

Installation: The modular system is designed for practical assembly and can be adapted to surface-mounted or prepared foundation installations. Final civil, drainage, water and electrical requirements should be confirmed before installation.

1. Confirm the maximum vehicle width, height, wheelbase and operating direction.
2. Prepare a level and structurally suitable installation base.
3. Assemble the main steel frame and secure all structural connections.
4. Install spray lines, nozzles and chemical-resistant hoses according to the approved layout.
5. Connect the pump, filter, dosing unit and control cabinet.
6. Position and align the vehicle detection sensors.
7. Check all valves, fittings, filters and electrical connections before commissioning.
8. Test automatic vehicle detection and manual control functions.
9. Check spray coverage and adjust nozzle orientation where required.
10. Clean filters regularly to maintain stable water flow.
11. Inspect nozzles, hoses, valves, pump components and fittings periodically.
12. Flush the spray circuit with clean water according to equipment and chemical requirements.
13. Inspect the galvanized and stainless-steel structure for damage, corrosion or chemical deposits.
14. Check drainage and wastewater collection components where installed.
15. Protect water and chemical lines against freezing in cold climates.

Q: What is a Mobile Vehicle Disinfection System for Farms?
A: It is a modular vehicle biosecurity system designed to apply a compatible disinfectant solution to vehicle exterior surfaces, wheels and chassis at a controlled farm entrance or biosecurity zone.

Q: Is it suitable for commercial pig farms?
A: Yes. The system can be configured for commercial pig farms, poultry farms, cattle farms, breeding facilities and other livestock production sites.

Q: Can the system operate automatically?
A: Yes. Vehicle detection sensors can activate the programmed spray cycle automatically, while manual operation can be provided for testing and maintenance.

Q: Can it disinfect vehicle wheels and chassis?
A: Yes. Lower spray lines and nozzles can be positioned specifically for wheel, underbody and chassis treatment.

Q: Can the system handle large livestock transport vehicles?
A: Yes. The arch width, height, vehicle clearance, structural capacity and spray arrangement can be designed according to the dimensions and operating requirements of the vehicle fleet.

Q: Can the disinfectant dosing rate be adjusted?
A: Yes. The chemical dosing system can be configured according to the selected compatible disinfectant and the farm's approved biosecurity procedure.

Q: Can a vehicle washing stage be added?
A: Yes. A separate high-pressure washing module can be integrated where the project requires cleaning before disinfectant application.

Q: Does the system require a concrete foundation?
A: The installation method depends on the selected configuration. Surface-mounted and prepared-foundation solutions are available according to site conditions and project requirements.

Q: Can wastewater be collected?
A: Yes. Drainage and wastewater collection components can be incorporated and coordinated with the farm's existing wastewater management system.

Q: Can the system be customized for international farm projects?
A: Yes. Dimensions, spray coverage, pump performance, chemical dosing, electrical configuration, structural materials, drainage and control functions can be designed according to local climate, farm conditions and project requirements.
