Custom Cut-and-Weld Pig Gate Panel

• Custom On-Site Length: Allows gate dimensions to be adjusted directly to the actual barn opening.
• Movable End Upright: The adjustable upright can be repositioned before final welding.
• Cut-and-Weld Construction: Excess horizontal rods and top rail can be removed after the final gate length is established.
• Heavy-Duty Steel Structure: Horizontal steel rods and reinforced structural members provide reliable pig containment.
• Ideal for Retrofit Projects: Useful when existing openings differ from standard manufactured gate dimensions.
• Flexible Accessories: Compatible with gate clips, latches, drop rods, posts, wall brackets and feeder connections.
• Easy Repair Solution: Suitable for replacing damaged divider or gate sections without rebuilding complete pen rows.
• Multiple Surface Finishes: Painted, galvanized or project-specific corrosion-resistant finishes are available upon request.
• Commercial Farm Application: Suitable for nursery, grower, finisher and other pig housing areas according to configuration.

• Horizontal Steel Rods: Form the primary gate barrier and withstand lateral animal pressure.
• Top Structural Rail: Provides longitudinal reinforcement across the gate panel.
• Fixed End Upright: Factory-positioned structural end member.
• Adjustable End Upright: Temporarily positioned so the installer can move it to the required gate length.
• Gate Clips: Connect the completed gate to drop rods, posts or adjoining pen structures.
• Latch Components: Flipper latches or other livestock locking systems are available according to project requirements.
• Gate Rods: Provide a simple hinge or pivot connection for compatible pig pen installations.
• Posts and Base Plates: Can be supplied where a free-standing gate support is required.
• Wall or Feeder Brackets: Allow the gate to connect to concrete walls, partitions or compatible feeding equipment.

• Nursery pig pen gates
• Wean-to-finish pig housing
• Grower and finisher pig pens
• Pig holding and sorting areas
• Service aisle access gates
• Feeder-side gate installations
• Replacement of damaged pig gates
• Non-standard barn openings
• Commercial pig house renovation
• New steel-structure pig farm projects

• Finished gate length
• Gate opening direction
• Steel rod and frame specifications
• Panel height
• Horizontal rod spacing
• Gate clip configuration
• Flipper latch or customized locking system
• Drop-rod connection
• Wall-mounted configuration
• Feeder-mounted configuration
• Free-standing structural posts
• Floor-mounted post and base-plate system
• Painted or galvanized surface treatment

• Measure the actual gate opening and confirm the required installation clearance.
• Release the temporarily positioned end upright.
• Move the upright along the horizontal rods to the required finished length.
• Confirm alignment and weld the horizontal rods and top rail securely to the upright.
• Cut or grind away the excess steel beyond the finished upright position.
• Install the required clips, hinge pipes, gate rods and latch components.
• Apply suitable corrosion protection to exposed steel and newly welded surfaces.
• Mount the gate to the post, wall, feeder or adjacent pen structure.
• Check gate clearance, hinge movement, latch engagement and weld quality before use.

• Inspect welds and horizontal rods regularly for mechanical damage.
• Check gate rods, clips, hinges and latches for excessive wear.
• Retighten post, wall and floor connections when required.
• Keep moving components free from manure and feed residue.
• Repair damaged protective coating after cutting, welding or mechanical impact.
• Replace worn latch components or brackets promptly.
• Include gate inspection in routine pig barn preventive maintenance.

Q: What is a cut-and-weld pig gate panel?
A: It is an adjustable steel gate panel supplied with a movable end upright so the installer can produce a custom finished gate length on site.

Q: Why use a cut-and-weld panel instead of a standard gate?
A: It is useful when an existing barn opening does not match a standard gate size or when replacement and renovation work requires an exact custom dimension.

Q: How is the gate length adjusted?
A: The movable upright is repositioned to the required location, welded to the rods and top rail, and the excess steel is then removed.

Q: What gate lengths can be produced?
A: Reference configurations include panels designed for approximately 6-9 ft and 9-12 ft finished gate ranges. Customized specifications are available upon request.

Q: Is welding equipment required?
A: Yes. Proper welding and metal-cutting equipment are required to complete the field adjustment safely and securely.

Q: Can different latch systems be installed?
A: Yes. Gate clips, flipper latches, drop rods and other livestock gate hardware can be selected according to project requirements.

Q: Can the gate connect directly to a feeder?
A: Yes. Compatible feeder brackets can be used when the pen layout requires the gate or divider to terminate at feeding equipment.

Q: Can galvanized versions be supplied?
A: Galvanized configurations and corrosion-resistant installation components are available according to project requirements.

Q: What information is needed for quotation?
A: Recommended information includes finished gate dimensions, pig category, barn opening size, mounting method, latch type, surface treatment and project quantity.
