Single-Sided Nursery Dry Feeder

The Single-Sided Nursery Dry Feeder is designed for post-weaning and nursery pigs requiring controlled access to dry feed in commercial swine production. Its compact single-sided configuration is suitable for installation along pen partitions, walls or service-side layouts where feeding access is required from one direction.

The feeder combines a corrosion-resistant stainless steel chassis, solid feeding-space dividers and a fine feed-flow adjustment mechanism to help maintain consistent feed presentation while reducing excessive feed accumulation.

Multiple feeder lengths and feeding-space configurations are available for different nursery pen sizes, stocking levels and pig farm construction projects.

• Single-Sided Feeding: Ideal for wall-side, fence-line and one-direction feeding layouts.
• 304 Stainless Steel Chassis: Provides corrosion resistance for humid nursery environments.
• Precise Feed Adjustment: Fine mechanical adjustment controls feed flow in small, repeatable increments.
• Multiple Feeding Spaces: Available in configurations with up to 10 feeding positions.
• Solid Feed Dividers: Help organize pig access and encourage orderly feeding behavior.
• Easy Cleaning: Quick-release features and an open lower design simplify removal and sanitation.
• Protected Edges: Folded and overlapped sheet-metal sections reduce exposed sharp edges and reinforce wear points.
• Flexible Mounting: Compatible with solid concrete, concrete slats, plastic nursery floors and gate-mounted installations.

• Feed Hopper: Stainless steel storage section for nursery dry feed.
• Feed Shelf: Presents controlled quantities of feed to the pigs.
• Feeding-Space Dividers: Separate individual feeding positions along the trough.
• Feed Adjustment Mechanism: Regulates the opening between the hopper and feeding area.
• Lower Trough Section: Provides convenient access to dry feed while helping contain displaced material.
• Quick-Release Components: Support easier removal for cleaning and barn maintenance.
• Mounting Holes and Brackets: Allow adaptation to different flooring and penning structures.

Dry feed is supplied manually or from a compatible automatic feed line into the hopper. Gravity moves the feed toward the lower dispensing opening.

The adjustment mechanism controls the size of this opening, allowing farm personnel to match feed flow to pig size, ration characteristics and consumption level.

Pigs access the feed from one side through separated feeding spaces. Correct adjustment maintains feed availability while helping reduce unnecessary feed buildup and wastage.

• Commercial nursery pig houses
• Post-weaning piglet facilities
• Single-sided fence-line feeding layouts
• Wall-side nursery pen installations
• Plastic or concrete slatted-floor barns
• Automatic dry-feed delivery projects
• Prefabricated steel structure pig houses
• Pig farm renovation and feeder replacement projects

• Feeder length
• Number and width of feeding spaces
• Feed-flow adjustment configuration
• Automatic feed-line connection
• Concrete-floor mounting
• Concrete-slat mounting
• Plastic nursery-floor mounting
• Gate or pen-partition mounting
• Complete configuration according to project requirements

Installation:

• Confirm feeder size, pig access direction, pen layout and floor type.
• Select mounting brackets suitable for the floor or penning structure.
• Position the feeder level and securely fasten all mounting points.
• Connect the hopper to a compatible automatic feed line where required.
• Set the initial feed opening according to pig size and feed characteristics.
• Check feeder stability, feed flow and animal access before commissioning.

Maintenance:

• Remove stale feed and accumulated material regularly.
• Adjust feed flow as pig size and ration characteristics change.
• Inspect dividers, adjustment components, rivets and mounting hardware.
• Use the quick-release arrangement when deeper cleaning is required.
• Wash and disinfect the feeder between nursery batches.
• Replace damaged or excessively worn components promptly.

Q1: What pigs is this feeder designed for?

It is designed primarily for post-weaning and nursery pigs, with reference configurations suitable for pigs up to approximately 27 kg.

Q2: Why choose a single-sided nursery feeder?

A single-sided feeder is useful when animal access is required from only one side, such as along walls, pen partitions or service-side layouts.

Q3: Can the feed flow be adjusted?

Yes. Fine mechanical adjustment allows the feed opening to be changed as pigs grow or feed characteristics vary.

Q4: How many feeding spaces are available?

Reference models are available with up to 10 feeding spaces, with other configurations available according to project requirements.

Q5: Can it be installed on plastic slatted flooring?

Yes. Suitable mounting systems can be supplied for plastic nursery floors, concrete slats, solid concrete and gate installations.

Q6: Is the feeder easy to clean?

Yes. Quick-release features and the lower notched construction help simplify removal and cleaning between production groups.

Q7: Can the feeder connect to an automatic feed line?

Yes. Feed-line integration can be provided according to the farm's automatic feeding system and project layout.

Q8: What information is required for a quotation?

Please provide the pig weight range, pigs per pen, required feeding-space quantity, pen dimensions, floor type, automatic feeding requirements and project location.
