Two-Sided Nursery Dry Feeder

• Two-Sided Feeding: Provides feeding access from both sides for efficient nursery pen layouts.
• 304 Stainless Steel: Corrosion-resistant construction suitable for humid pig-house conditions.
• Adjustable Feed Flow: Fine adjustment helps match feed delivery to pig size and feed characteristics.
• Solid Feeding Dividers: Separate feeding positions and help reduce interference between piglets.
• Reduced Feed Waste: Controlled feed presentation helps prevent excessive feed buildup in the trough.
• Quick-Removal Design: Compatible configurations simplify feeder removal for washing and sanitation.
• Folded and Lapped Edges: Reduce exposed sharp edges and reinforce high-wear areas.
• Flexible Mounting: Multiple mounting points support different flooring and pen configurations.
• Multiple Sizes: Different feeder lengths and feeding-space arrangements are available.

• Stainless Steel Hopper: Stores dry nursery feed above the feeding area.
• Feed Adjustment Mechanism: Regulates feed discharge from the hopper.
• Two-Sided Trough: Provides feed access to pigs on both sides.
• Solid Dividers: Create organized individual feeding spaces.
• Riveted Chassis: Provides a practical and lightweight feeder structure.
• Quick-Latch Components: Facilitate removal and cleaning in compatible installations.
• Mounting Holes and Knockouts: Allow connection to different barn floor and pen systems.

• Commercial nursery pig houses
• Weaning and piglet rearing barns
• Two-pen shared feeding layouts
• Central pen-line feeder installations
• Automatic dry-feed systems
• New steel-structure pig houses
• Existing nursery barn renovation projects

• Feeder length
• Number of feeding spaces
• Feeding-space arrangement
• Feed-flow adjustment configuration
• Automatic feed-drop connection
• Concrete floor mounting
• Concrete slat mounting
• Plastic nursery floor mounting
• Gate or partition mounting
• Supplemental watering accessories

• Confirm feeder size, pen layout and feeding-space requirements before installation.
• Position the feeder so pigs have clear access from both sides.
• Select mounting hardware suitable for the existing flooring or pen structure.
• Level and securely fasten the feeder.
• Connect the feed-drop tube when used with an automatic feeding system.
• Set the initial feed opening according to pig size and feed characteristics.

• Remove stale feed and accumulated dust regularly.
• Clean and disinfect the trough between production groups.
• Use the quick-release design where applicable for thorough cleaning.
• Inspect the adjustment mechanism for smooth movement.
• Check dividers, rivets and mounting hardware periodically.
• Adjust feed flow as pig size and feed characteristics change.

Q: What pigs is this feeder designed for?
A: It is intended for nursery pigs, with the referenced configuration suitable for pigs up to approximately 27 kg.

Q: Why use a two-sided nursery feeder?
A: Two-sided access allows one feeder to serve pigs from both sides and can improve space utilization in central pen layouts.

Q: Is feed flow adjustable?
A: Yes. The feed outlet can be finely adjusted to match pig size, feed form and desired feed presentation.

Q: How many feeding spaces are available?
A: Referenced configurations are available with up to 10 feeding spaces per side.

Q: Can it be mounted on plastic nursery flooring?
A: Yes. Suitable mounting accessories can be used for plastic flooring as well as concrete and concrete slats.

Q: Is the feeder easy to clean?
A: Yes. Smooth stainless surfaces and compatible quick-release features simplify routine cleaning and sanitation.

Q: What information is required for quotation?
A: Recommended information includes pig weight range, pigs per pen, number of pens, required feeding spaces, flooring type, feed-delivery system and project quantity.
