Product Showcase	Content
Product Name	Ultra-Narrow Pig House Feed Cart
Product Image
Product Overview	The Ultra-Narrow Pig House Feed Cart is designed for commercial swine facilities with restricted feeding aisles and limited turning space. Its slim-profile body allows operators to transport dry feed, livestock supplies and routine farm materials through narrow passages where conventional wide feed carts may be difficult to use. A durable polymer tub, stable wheel arrangement and compact chassis provide a practical solution for gestation houses, farrowing barns, nursery rooms and grow-finish buildings. Overall dimensions and capacity can be customized according to pig-house aisle width and project requirements.
Key Features	Ultra-narrow body configuration for restricted pig-house aisles. Compact footprint improves maneuverability around pens, gates and feeding equipment. Heavy-duty polymer tub provides corrosion resistance in humid livestock environments. Smooth internal surfaces simplify feed removal, washing and sanitation. Rolled or rounded tub edges improve handling safety and structural rigidity. Reinforced lower structure supports routine feed transport loads. Large fixed wheels combined with swivel casters provide stable movement and easy steering. Manual operation requires no battery, motor or permanent installation. Dimensions, wheel arrangement and capacity can be customized for individual farm projects.
Structural Components	Polymer Feed Tub: Durable molded container for carrying dry feed and farm materials. Reinforced Double-Floor Structure: Provides additional support beneath the feed compartment. Rolled Tub Edges: Strengthen the upper rim and provide smoother contact surfaces. Narrow Chassis: Designed to minimize overall cart width for confined livestock-house passages. Fixed Wheels: Support the primary load and provide stable straight-line movement. Swivel Casters: Improve turning performance in tight corners and pen aisles. Push Handle: Allows controlled manual movement and positioning by the operator.
Working Principle / Structural Principle	Feed is loaded into the open-top tub at the feed preparation or storage area. The operator manually pushes the cart through the pig-house aisle and distributes feed at individual pens, troughs or feeders. The narrow body keeps the cart within restricted passage widths, while the fixed wheels carry the main load and the swivel casters assist steering. This configuration allows efficient movement through tight barn layouts without requiring powered drive equipment.
Technical Specifications	Product Type Manual Narrow-Aisle Feed Transport Cart Primary Application Pig House Feed and Supply Transport Tub Material Heavy-Duty Polymer / Polyethylene Type Material Operation Manual Push / Pull Reference Narrow-Aisle Width Approximately 18.5 in / 470 mm class Reference Overall Dimensions Approx. 39.25 in L × 18.5 in W × 35 in H for comparable narrow-profile configuration Production Dimensions Customizable According to Project Requirements Feed Capacity Available Upon Request Wheel Configuration Fixed Wheels with Swivel Caster Options Wheel Type Semi-Pneumatic, Pneumatic or Project-Specific Options Applicable Feed Dry Meal Feed, Pellet Feed and Compatible Farm Materials
Applications	Commercial pig farms with narrow feeding aisles Sow gestation and breeding houses Farrowing barns Piglet nursery buildings Grower and finisher pig houses Feed transport between storage rooms and individual pens Livestock buildings with restricted doorway or passage width Pig farm renovation projects with existing compact layouts Daily transport of feed, veterinary supplies and farm tools
Customization Options	Overall width according to pig-house aisle dimensions Feed tub length, height and capacity Fixed wheel and swivel caster configuration Wheel diameter and wheel material Tub material and color Handle height and operating position Internal divider or cover options Drainage configuration where required OEM branding and export packaging
Installation & Maintenance	The cart is a standalone manual unit and requires no permanent installation. Depending on the shipping configuration, wheels, casters or handles may require simple assembly before use. Remove residual feed regularly and wash the tub according to farm hygiene procedures. Inspect wheel bearings, caster rotation, axle fasteners, handles and structural connections periodically. Keep wheels free from manure, feed residue and other debris to maintain smooth movement through narrow passages.
Product FAQ	Q: What makes this cart suitable for narrow pig-house aisles? A: Its slim body and compact wheel arrangement reduce overall width while maintaining sufficient capacity for routine feed transport. Q: Can the width be customized? A: Yes. Overall width can be designed according to the minimum clear aisle width of the pig house. Q: Is the cart suitable for commercial pig farms? A: Yes. It is designed for repetitive feed and material handling in gestation, farrowing, nursery and grow-finish facilities. Q: Does the cart require electrical power? A: No. It is manually operated and requires no battery, motor or charging system. Q: Can different wheel systems be supplied? A: Yes. Fixed wheels, swivel casters and different tire configurations are available according to floor conditions and project requirements. Q: Can the cart be supplied with a cover or internal divider? A: Cover and divider configurations can be provided where required for specific feed handling applications.
Product Gallery
