Automatic Chick Eye Drop Vaccinator

• Automatic dispensing for repeatable ocular vaccine application.
• Adjustable metering configuration for compatible vaccination protocols.
• Electric operation with no external compressed-air supply required for standard models.
• Integrated counter supports flock and batch recording.
• Ergonomic chick positioning area for efficient one-operator use.
• Visible drop formation supports administration checks.
• Compact tabletop structure is easy to install in hatchery work areas.
• Accessible liquid-contact parts simplify cleaning and replacement.
• Reduces operator fatigue during repetitive vaccination work.
• Voltage, nozzle, reservoir and accessories can be customized.

Final specifications should be confirmed according to the selected model and vaccination protocol.

• Commercial poultry hatcheries
• Broiler chick vaccination programs
• Layer and breeder chick vaccination
• Pullet-rearing facilities
• Poultry breeding and research centers
• Veterinary vaccination service teams
• Integrated hatchery construction projects
• Livestock equipment distributors and agricultural project contractors

• Dispensing volume and nozzle configuration
• Vaccine reservoir capacity
• Integrated vaccine cooling module
• Voltage, frequency and electrical plug
• Counter and batch-recording functions
• Vaccination table or mobile workstation
• Spare-parts and maintenance packages
• Private-label packaging for distributors
• Configuration according to hatchery capacity and project requirements

1. Place the machine on a stable, clean and dry vaccination table.
2. Install the reservoir, tubing and nozzle according to the operating instructions.
3. Prime the liquid circuit and remove visible air bubbles.
4. Check the delivered volume before every vaccination batch.
5. Keep the nozzle above the eye without touching the bird.
6. Remove residual vaccine and clean the approved liquid-contact parts after use.
7. Inspect tubing, seals, connectors and the nozzle regularly.
8. Replace worn or contaminated components when required.
9. Follow the vaccine manufacturer’s instructions for preparation, temperature control and disposal.

Q1: What birds can be vaccinated with this machine?

It is primarily designed for day-old chicks and may be configured for other compatible young poultry.

Q2: Can the drop volume be adjusted?

The metering system can be configured for selected dose volumes. Calibration must follow the vaccine supplier’s instructions.

Q3: How is correct vaccination confirmed?

The operator should visually confirm that a complete drop has entered the open eye and allow the chick to blink before release.

Q4: Does the machine require compressed air?

The standard electric configuration does not require an external compressed-air supply.

Q5: Is a vaccine cooling system available?

An integrated or external cooling arrangement can be supplied according to project requirements.

Q6: Can the equipment be supplied for international projects?

Power supply, plug type, accessories, spare parts and packaging can be customized for the destination market.
