Product Showcase	Content
Product Name	Diaphragm Pig Water Level Controller
Product Image
Product Overview	The Diaphragm Pig Water Level Controller is a non-electric automatic water regulator designed to maintain a stable water level in pig drinking bowls, troughs and compatible through-feeding systems. A flexible diaphragm responds to changes in air and water pressure, automatically opening the inlet when the water level falls and closing it when the preset level is restored. This simple mechanical principle provides continuous water availability without electrical sensors or float arms inside the drinking area.
Key Features	Automatically maintains a preset drinking-water level. High-quality diaphragm provides reliable sealing and automatic shutoff. Non-electric operation simplifies installation and reduces maintenance requirements. Automatic replenishment keeps clean water continuously available to pigs. Helps reduce overflow, unnecessary water consumption and slurry volume. No conventional float arm is required inside the drinking trough. Front-end ball valve allows convenient isolation during servicing. Suitable for drinking basins, troughs and gestation through-feeder systems.
Structural Components	Controller Housing: Protects the internal regulating mechanism in livestock-house environments. Flexible Diaphragm: Opens and closes the water passage according to pressure conditions. Water Inlet: Connects the controller to the farm drinking-water supply. Water Outlet: Transfers regulated water toward the drinking bowl or trough. Level-Sensing Tube: Establishes the target water level through atmospheric-pressure control. Fastening Assembly: Secures the controller housing and maintains diaphragm sealing. Upstream Ball Valve: Allows individual controller isolation for inspection or maintenance.
Working Principle / Structural Principle	The controller uses an air-diaphragm water-level principle. The lower end of the sensing or outlet tube is positioned at the required water level inside the drinking bowl or trough. When pigs drink and the water surface falls below the tube opening, air enters the control chamber and the diaphragm allows water to flow into the drinking area. As the water rises and covers the tube opening, the pressure condition changes and the diaphragm closes the inlet. The cycle repeats automatically as pigs consume water, maintaining the drinking level without electrical control equipment.
Technical Specifications	Product Type Automatic Pig Water Level Controller Control Principle Air / Water Pressure Diaphragm Control Power Requirement None Water Level Adjustable by Installation / Outlet Tube Position Diaphragm Flexible Sealing Diaphragm Water Inlet Connection According to Project Requirements Outlet Connection According to Drinking Bowl / Trough Configuration Operating Water Pressure According to Selected Model and Farm Water System Recommended Isolation Individual Upstream Ball Valve Application Pig Drinking Bowls, Troughs and Through-Feeding Systems
Applications	Commercial pig breeding farms Gestation pens and sow group-housing systems Through-feeder drinking systems Pig drinking basins and water troughs Nursery, grower and finishing pig facilities with compatible trough systems Centralized pig-house drinking-water installations New pig farm construction and water-system renovation projects
Customization Options	Water inlet and outlet connection sizes Level-sensing tube length Target drinking-water level Controller housing configuration Ball valve and filter combinations Pipe and drinking-trough connection kits Complete pig-house water distribution assemblies OEM branding and bulk export packaging
Installation & Maintenance	Install the controller above or beside the drinking trough according to the selected system layout. Connect the inlet to the clean-water supply and position the lower end of the sensing or outlet tube at the required water level. An individual ball valve should be installed upstream so the controller can be isolated for maintenance. Flush new pipelines before commissioning and use suitable filtration where water contains sediment. Periodically inspect the diaphragm, sealing surfaces, inlet valve, pipe connections and sensing tube. Remove mineral deposits or debris and replace worn diaphragm components when necessary.
Product FAQ	Q: Does the water level controller require electricity? A: No. It operates mechanically through diaphragm, atmospheric-pressure and water-pressure changes. Q: How does it maintain a constant water level? A: When the water drops below the sensing-tube opening, the controller replenishes the trough. When water reaches the preset level, the diaphragm closes the inlet automatically. Q: Can the water level be adjusted? A: Yes. The target level can be set through the installation position and sensing or outlet tube configuration. Q: Why is a ball valve installed before the controller? A: The ball valve allows one controller to be isolated for cleaning or maintenance without shutting down the complete pig-house water system. Q: What drinking equipment can it be used with? A: It can be integrated with compatible pig drinking bowls, troughs, pen drinking basins and gestation through-feeding systems. Q: Can complete water-level control assemblies be supplied? A: Yes. Controllers, valves, pipes, sensing tubes, fittings and drinking trough components can be configured according to project requirements.
Product Gallery

```
