Electric Fine Mist Disinfection Fogger

• Mobile electric fine mist fogging unit
• 20 L translucent solution tank
• Flexible hose with handheld atomizing head
• Stainless steel mobile support frame
• Four-wheel trolley for easy movement
• Adjustable spray output for different applications

• 1800 W Electric Power: High-output electric motor provides strong airflow for fine mist distribution.
• Adjustable Output: Spray intensity can be regulated according to treatment and coverage requirements.
• 20 L Solution Tank: Large-capacity tank supports extended farm spraying operations with fewer refills.
• 6–10 m Spray Distance: Long horizontal reach improves coverage inside livestock and poultry buildings.
• 5–8 m Spray Height: Suitable for distributing mist into larger animal-house spaces.
• Flexible Spray Hose: Handheld atomizing head allows the operator to direct mist toward selected areas.
• Durable Construction: Copper motor, ABS plastic components and stainless steel frame support frequent farm use.
• Mobile Trolley Design: Four caster wheels simplify movement between barns, pens and work areas.
• Multiple Farm Uses: Suitable for compatible disinfection, poultry spray applications, humidification and dust suppression.

• Pig house space spraying
• Poultry house disinfection programs
• Poultry spray vaccination according to approved protocols
• Compatible veterinary solution atomization
• Livestock-house humidification
• Dust suppression in animal buildings
• Breeding and quarantine facilities
• Farm equipment and service-area treatment
• General agricultural fine mist applications

• Place the machine on a stable, level surface before filling the solution tank.
• Check that the electrical supply matches the machine configuration before operation.
• Fill the tank only with clean water or compatible prepared solutions.
• Adjust the spray output gradually to obtain the required mist pattern.
• Keep the air inlet and motor ventilation openings clean to maintain effective heat dissipation.
• Inspect the flexible hose, atomizing head, tank and fittings regularly for leakage or blockage.
• Flush the tank and spraying system with clean water after using treatment solutions when required.
• Do not operate the unit with incompatible corrosive chemicals unless compatibility has been confirmed.
• Disconnect electrical power before cleaning, inspection or maintenance.
• Store the machine clean and dry when not in use.

Q: What is the rated power of the fogger?
A: The listed power is 1800 W with adjustable spray output.

Q: What is the solution tank capacity?
A: The machine is equipped with a 20 L solution tank.

Q: How far can the machine spray?
A: The specified horizontal spray distance is approximately 6–10 m.

Q: What is the maximum spray height?
A: The listed spray height is approximately 5–8 m.

Q: Is it suitable for livestock farms?
A: Yes. It is designed for applications such as livestock-house spraying, compatible disinfection, humidification and dust control.

Q: Can it be used for poultry spray vaccination?
A: It can be used for suitable poultry spray applications when the vaccine, droplet requirements and operating procedure are approved by the vaccine manufacturer and veterinary protocol.

Q: Can the spray volume be adjusted?
A: Yes. The listed configuration provides adjustable output for different misting requirements.

Q: How should the machine be cleaned after use?
A: Empty the remaining solution, flush the tank and spray circuit with clean water when appropriate, and keep the atomizing head and air inlet clean before storage.
