Shear Beam Weighing Module for Feed Silos

Reference image of a shear beam weigh module kit. The supplied configuration is confirmed for each project.

• Shear beam load cell design supports weighing at individual silo legs.
• Mounting assembly provides a defined load path between the leg and foundation.
• Multi-module arrangements can be specified to match the number of silo supports.
• Suitable for inventory monitoring in commercial livestock feeding operations.
• Module material, environmental protection, and restraint details can be selected according to project requirements.

• Load cell type: Shear beam
• Number of modules: According to silo support arrangement
• Rated capacity per module: Selected according to total load and structural design
• Mounting dimensions and hole pattern: Customizable
• Module material and environmental protection: Available upon request
• Junction box, indicator, and communication interface: According to project requirements

Capacity selection must account for the empty silo, maximum feed load, uneven load distribution, and site-specific forces. Final accuracy and environmental ratings require confirmation for the selected components.

How many modules does one feed silo need?
The arrangement normally follows the number and design of the silo's load-bearing supports. The final selection requires a review of the silo drawings.

Can modules be fitted to an existing silo?
A retrofit may be possible after checking the support legs, foundation, anchor points, and temporary support method needed for installation.

Can the system show remaining feed?
Yes. With suitable calibration and an indicator, changes in silo weight can be used to monitor feed inventory.

What information is needed for selection?
Please provide the silo drawing, number of legs, empty weight, maximum feed load, foundation details, site conditions, and required display or data interface.

Gallery images are equipment and application references, not photographs of a confirmed SHEWUYOU installation.
