Automatic Cattle Footbath System

• Automatic filling, dosing, flushing and refill functions.
• Durable stainless-steel construction for demanding livestock environments.
• Controlled hoof-treatment cycles for more consistent herd management.
• Automatic or programmed operation according to system configuration.
• Reduced manual mixing, filling and cleaning workload.
• Designed for integration with cattle handling and milking facility layouts.
• Optional control and dosing configurations according to project requirements.
• Suitable for high-throughput commercial dairy and cattle operations.
• Configuration can be adapted for new construction or suitable facility upgrades.

• Footbath Trough: Stainless-steel treatment basin designed to contain hoof-care solution.
• Side Panels: Help guide cattle through the treatment zone and reduce solution splash-out.
• Drainage Assembly: Provides controlled discharge of used treatment solution.
• Water Supply System: Connects the bath to the farm water supply for filling and rinsing.
• Chemical Dosing Unit: Metering components introduce hoof-care products according to the selected operating program.
• Control System: Manages filling, dosing, flushing and operating cycles according to configuration.
• Wash and Flush System: Supports removal of manure and residual solution during cleaning cycles.

• Commercial dairy farms and large-scale cattle operations.
• Milking parlour exit lanes and cow return alleys.
• Automated milking system facilities.
• Cattle hoof-care stations and herd-health management areas.
• New dairy barn construction and livestock facility modernization projects.
• Retrofit projects requiring automated footbath management.
• Veterinary and professional cattle hoof-care service facilities.
• Livestock equipment distributors, agricultural engineering companies and farm project contractors.

• Footbath length, width and overall configuration: Customizable.
• Side-panel height and guiding structure: According to project requirements.
• Water inlet and drainage connections: Designed according to local facility conditions.
• Chemical dosing configuration: Customizable.
• Control method and operating sequence: According to project requirements.
• Single or multiple treatment-stage configuration: Available upon request.
• Stainless-steel grade and surface finish: Customizable.
• Electrical control cabinet configuration: According to local standards and project requirements.
• OEM branding, identification and packaging: Available upon request.

• Install on a stable, level foundation suitable for livestock traffic.
• Position the footbath along a natural cattle movement route.
• Coordinate water supply, drainage and electrical connections before commissioning.
• Provide adequate working clearance around pumps, controls and service points.
• Final installation should follow the supplied technical drawings and local electrical and livestock-facility requirements.

• Inspect the bath, drainage outlet and water connections regularly.
• Remove manure and accumulated solids from the treatment area.
• Clean the bath and flushing system according to the operating schedule.
• Inspect dosing pumps, tubing and connections for leakage or blockage.
• Check sensors, control components and electrical connections periodically.
• Inspect stainless-steel surfaces and drainage components for damage or abnormal corrosion.
• Follow the chemical manufacturer's handling, storage and concentration instructions.

Q1: What is an automatic cattle footbath system?
A1: It is an automated hoof-care station that manages footbath filling, treatment-solution dosing, drainage and flushing with reduced manual intervention.

Q2: Where should the footbath be installed?
A2: Common locations include milking parlour exits, return lanes and other areas where cattle naturally pass through. The final position should be planned according to traffic flow and farm layout.

Q3: Can the footbath be customized for a new dairy barn?
A3: Yes. Dimensions, side panels, drainage, dosing equipment, controls and connection arrangements can be designed according to project requirements.

Q4: Does the system automatically add hoof-care chemicals?
A4: An automatic dosing configuration can be provided. The selected chemical and treatment concentration should be determined according to the farm's hoof-care program and professional guidance.

Q5: Is stainless steel suitable for dairy farm environments?
A5: Stainless steel is widely used for livestock equipment exposed to water, cleaning processes and corrosive farm conditions. The material grade can be selected according to the application.

Q6: Can SHEWUYOU provide complete project customization?
A6: Yes. The system can be configured according to herd size, cattle traffic, building layout, local climate, drainage conditions and project requirements.
