304 Stainless Steel Pass-Through Pig Scale

• 304 Stainless Steel Construction: Provides excellent resistance to water, rust and corrosion in demanding pig-house environments.
• Pass-Through Design: Front and rear gates allow pigs to enter from one side and exit from the other for efficient animal flow.
• Single-Operator Gate Control: Mechanical control lever allows the operator to control the opposite gate from one working position.
• Four Precision Load Cells: Four stainless steel weighing sensors provide stable load distribution and reliable measurement.
• Waterproof Indicator: Stainless steel weighing indicator is suitable for humid livestock environments and routine cleaning.
• Washable & Disinfectable: Stainless construction is well suited to farms requiring frequent washing and biosecurity sanitation.
• Mobile Wheel System: Integrated wheels and handles allow one person to move the scale between suitable locations.
• Narrow Passage Configuration: Suitable for livestock houses with limited aisle width and restricted weighing space.
• Optional Smart Identification: RFID ear-tag recognition and weighing-data upload functions can be added according to project requirements.

• Commercial pig farms
• Breeding pig farms
• Pig sorting and grading areas
• Finishing pig weighing
• Livestock transfer passages
• Pre-sale body-weight monitoring
• High-biosecurity pig facilities
• Narrow livestock-house aisles
• Areas requiring frequent washing and disinfection

• Place the scale on a firm, level surface before weighing.
• Adjust the support feet so the weighing platform is stable and does not rock.
• Confirm that the indicator displays zero before each pig enters the scale.
• Guide pigs calmly through the passage to reduce animal stress and excessive movement.
• Check that both gates and the mechanical control lever operate freely before use.
• Remove manure and feed residue from the platform after weighing sessions.
• Wash and disinfect stainless steel surfaces according to farm biosecurity procedures.
• Avoid directing high-pressure water jets directly at electrical connectors or sensitive weighing components unless specifically rated for such cleaning.
• Inspect load cells, signal cables, wheels, hinges, gates and fasteners regularly.
• Verify weighing accuracy periodically and recalibrate the scale when required.

Q: What material is the scale made from?
A: The primary configuration uses 304 stainless steel for excellent corrosion resistance and convenient cleaning.

Q: What is the standard reference capacity?
A: A common reference configuration is 500 kg. Other capacities can be supplied according to project requirements.

Q: Can one person operate the scale?
A: Yes. The control lever allows one operator to control the opposite gate without walking around the scale.

Q: Why is a pass-through design useful?
A: Pigs enter through one gate and leave through the opposite gate, improving animal flow and reducing the need to turn animals around.

Q: Can the scale be washed and disinfected?
A: Yes. The stainless steel body and waterproof indicator are designed for humid farm environments and routine sanitation procedures.

Q: Is the scale easy to move?
A: Yes. Integrated handles and mobile wheels allow one operator to relocate the unit within suitable farm areas.

Q: Can RFID ear-tag identification be added?
A: Yes. Electronic ear-tag recognition and weighing-data upload functions are available as upgrade options.

Q: Can the dimensions be customized?
A: Yes. Platform length, width, fence configuration, weighing capacity and indicator options can be adapted to different pig-house passages and farm requirements.
