Automatic Eye Drop Vaccinator with Vaccine Cooling System

The Automatic Eye Drop Vaccinator with Vaccine Cooling System is designed for controlled ocular administration of suitable live poultry vaccines to day-old chicks. It combines electronically controlled droplet dispensing with vaccine temperature management to support consistent vaccination quality during hatchery operations.

The equipment can be activated by a sensor, push button or operator control depending on configuration. A measured vaccine droplet is formed and held at the nozzle until the chick's eye contacts and absorbs the drop. An electronic counting function can record completed vaccination cycles, while the integrated cooling arrangement helps limit warming of prepared vaccine during continuous operation.

• Designed for individual eye-drop vaccination of day-old poultry chicks.
• Sensor-operated or switch-controlled vaccine dispensing.
• Electronic adjustable dosing for repeatable droplet delivery.
• Droplet-stay function keeps the vaccine drop suspended at the dispensing nozzle before application.
• Integrated counting function for recording vaccinated chicks.
• Vaccine cooling chamber or gel-filled cooling arrangement helps maintain vaccine temperature during operation.
• All-electric configuration available for convenient hatchery installation.
• Compact, portable design for commercial vaccination workstations.
• Sturdy metallic construction suitable for routine livestock equipment applications.
• Simple operating sequence supports standardized hatchery procedures.

• Main metallic equipment housing and support frame
• Electronic dosing control module
• Sensor or operator activation control
• Vaccine bottle or reservoir holder
• Vaccine cooling chamber or gel-filled cooling jacket
• Liquid delivery tubing
• Precision eye-drop dispensing nozzle
• Electronic chick counter
• Power supply and electrical control components
• Optional battery-supported configuration
• Consumable spares and maintenance tool kit

Prepared vaccine is connected to the liquid delivery system and maintained in the cooled holding area. When the operator activates the equipment or the sensor detects the required operating position, the dosing mechanism releases a controlled vaccine droplet to the dispensing nozzle.

The droplet remains suspended at the nozzle rather than falling immediately. The operator positions the chick so that the open eye contacts the droplet and absorbs the vaccine. After the vaccination cycle, the electronic counter can increase the recorded chick total.

The cooling system uses a cooling chamber or gel-filled cooling jackets around the vaccine container to help reduce heat transfer and support cold-chain management during hatchery vaccination.

Reference specifications are based on comparable commercial equipment. Final dosage and operating procedures must follow the vaccine manufacturer's approved instructions and the applicable veterinary vaccination program.

• Commercial poultry hatcheries
• Broiler chick hatcheries
• Layer chick hatcheries
• Breeder chick hatcheries
• Poultry breeding companies
• Integrated poultry production groups
• Veterinary vaccination stations
• Hatchery automation and livestock equipment projects
• Poultry equipment distributors and agricultural project contractors

• Sensor-operated activation configuration
• Push-button or alternative operator control
• Adjustable vaccine dosing configuration
• Electronic counting system
• Cooling chamber configuration
• Gel-filled vaccine cooling jacket
• Optional battery-supported power supply
• Electrical configuration according to destination market
• Workstation arrangement according to hatchery layout
• Consumable spares and maintenance kits available upon request
• OEM configuration according to project requirements

The vaccinator is normally positioned on a stable hatchery workbench close to the chick handling area. The working height, sensor position and dispensing nozzle should allow comfortable and repeatable chick handling while providing convenient access to the vaccine cooling compartment.

• Inspect the dispensing nozzle, sensor and vaccine tubing before operation.
• Pre-cool the vaccine holding arrangement before beginning vaccination where required.
• Prime the vaccine circuit and verify stable droplet formation.
• Confirm the required dose according to the approved vaccine protocol.
• Monitor vaccine temperature throughout extended vaccination sessions.
• Clean vaccine-contact components immediately after use.
• Replace worn tubing, seals and dispensing components when required.
• Protect electrical components from direct water during cleaning.
• Follow applicable hatchery hygiene, vaccine handling and biosecurity procedures.

Q: What is the purpose of the vaccine cooling system?
A: The cooling arrangement helps reduce warming of prepared live vaccine during continuous hatchery operation. Depending on configuration, a cooling chamber or gel-filled cooling jacket can be used.

Q: How is each eye-drop dose activated?
A: The equipment can use sensor activation, push-button control or another operator-controlled method according to the selected configuration.

Q: Does the vaccine drop fall automatically from the nozzle?
A: The dispensing design can hold the prepared droplet at the nozzle until the chick's eye contacts and absorbs it, supporting controlled application.

Q: Can the equipment count vaccinated chicks?
A: Yes. An electronic counting function can record completed vaccination cycles and support hatchery production records.

Q: Can the vaccination dose be adjusted?
A: Yes. The dosing system is adjustable within the applicable equipment range. The final setting must comply with the vaccine manufacturer's instructions.

Q: Can SHEWUYOU supply customized configurations?
A: Yes. Dosing, control method, cooling arrangement, electrical supply, spare parts and workstation requirements can be customized according to project requirements.
