Sensor-Operated Poultry Eye Drop Vaccinator

The Sensor-Operated Poultry Eye Drop Vaccinator is a compact vaccination device developed for controlled administration of liquid vaccines to day-old chicks. It is suitable for hatcheries and poultry breeding operations where individual eye-drop vaccination must be carried out with consistent dosing and efficient chick handling.

A sensor or operator control initiates the dispensing cycle and forms a suspended vaccine droplet at the delivery nozzle. The chick's eye is brought into contact with the droplet for uptake, while the integrated control system can record the vaccination count. Vaccine cooling can also be incorporated to support temperature management during continuous hatchery operation.

• Sensor-operated or operator-controlled vaccination cycle.
• Controlled eye-drop delivery for individual day-old chicks.
• Adjustable electronic dosing system.
• Droplet-stay design keeps the prepared drop suspended at the nozzle until application.
• Integrated electronic counting for recording vaccinated chicks.
• Vaccine cooling arrangement available for maintaining suitable operating temperature.
• Compact and portable design for commercial hatchery workstations.
• Durable metallic construction for routine livestock equipment applications.
• Simple operating procedure helps standardize vaccination workflow.

• Main metallic equipment housing
• Electronic control module
• Chick-position detection sensor
• Push-button or foot-switch control option
• Adjustable vaccine dosing mechanism
• Precision eye-drop dispensing nozzle
• Vaccine reservoir and liquid delivery tubing
• Electronic chick counter
• Vaccine cooling chamber or gel-jacket cooling arrangement
• Power supply and electrical control connections
• Consumable spare parts and maintenance accessories

Prepared vaccine is supplied to the dosing mechanism through the vaccine line. When the sensor detects the operating position, or when the operator activates the control, the system dispenses a measured droplet and holds it at the end of the nozzle.

The operator carefully positions the chick so that the eye contacts and absorbs the suspended droplet. After each vaccination cycle, the electronic counter increases the recorded bird quantity.

Where configured, the vaccine reservoir is surrounded by a cooling chamber or gel-filled cooling jacket to help reduce temperature increase during continuous operation.

Final dosing parameters and vaccination procedures must follow the vaccine manufacturer's instructions and the approved veterinary vaccination program.

• Commercial poultry hatcheries
• Broiler chick hatcheries
• Layer chick hatcheries
• Broiler breeder and layer breeder hatcheries
• Poultry breeding companies
• Integrated poultry production groups
• Veterinary vaccination stations
• Hatchery equipment and livestock equipment projects
• Poultry equipment distributors and agricultural project suppliers

• Sensor-operated control configuration
• Push-button or foot-switch operation
• Adjustable dosage configuration
• Electronic counting system
• Vaccine cooling chamber
• Gel-jacket vaccine cooling arrangement
• Battery backup available upon request
• Power supply adapted to destination market requirements
• Workstation layout according to hatchery project requirements
• Consumable spare-parts kits available upon request

The vaccinator can be installed on a stable workbench within the chick vaccination area. Equipment position and working height should allow comfortable chick handling and clear access to the dosing nozzle.

• Check the sensor, nozzle and vaccine tubing before operation.
• Prime the vaccine circuit and confirm stable droplet formation before vaccination.
• Confirm the required dose according to the approved vaccination protocol.
• Keep vaccine-contact components clean throughout operation.
• Flush and clean the liquid circuit after each vaccination session.
• Inspect tubing, seals and nozzles regularly and replace worn consumables.
• Keep electrical control components dry during cleaning.
• Follow applicable hatchery hygiene and biosecurity procedures.

Q: What birds is this vaccinator designed for?
A: It is primarily designed for individual eye-drop vaccination of day-old chicks in commercial hatcheries.

Q: How does the sensor-operated system work?
A: The sensor activates the dosing cycle and produces a measured vaccine droplet at the nozzle. The operator then positions the chick's eye to absorb the suspended droplet.

Q: Can the vaccination dose be adjusted?
A: Yes. The dosing system can be configured according to the applicable vaccine protocol and project requirements.

Q: Does the equipment count vaccinated chicks?
A: Yes. An electronic counting function can record the number of completed vaccination cycles.

Q: How is vaccine temperature controlled?
A: A cooling chamber or gel-filled cooling jacket can be used to help keep prepared vaccine cool during operation.

Q: Can the equipment be customized for different hatchery projects?
A: Yes. Control method, dosage configuration, electrical supply, cooling arrangement and accessories can be customized according to project requirements.
