Product Name	Automatic Poultry Harvesting System
Product Image
Product Overview	The Automatic Poultry Harvesting System is a mechanized broiler collection and loading solution developed for commercial poultry farms where fast flock removal, controlled bird handling and reduced dependence on manual catching are required. The system uses a mobile harvesting head and multiple conveyor sections to collect broilers from the poultry house floor and transfer them progressively toward a centralized caging or container loading unit. Birds move through the harvesting process by controlled conveyor motion rather than conventional manual carrying. The equipment can be configured as part of a complete poultry loading line including harvesting conveyors, central transfer channels, adjustable loading belts, automatic weighing functions and container handling equipment. The layout can be adapted to existing poultry houses or incorporated into new steel structure poultry building projects.
Key Features	Mechanized broiler collection reduces repetitive manual catching and carrying operations. Wide collection conveyors provide a controlled pathway for birds to enter the harvesting system. Progressive conveyor transfer helps avoid abrupt movement between harvesting and loading stages. Centralized bird transfer allows continuous movement toward poultry transport containers. Adjustable loading conveyor can be configured for different crate or container positions. Automatic weighing can be incorporated to support consistent loading quantities. Mobile tracked or wheeled configurations are available according to poultry house conditions. Washable structural components facilitate cleaning and farm biosecurity management. Modular construction allows configuration according to house width, loading route and project requirements. Suitable for commercial broiler farms, poultry integration projects and high-volume harvesting operations.
Structural Components	Harvesting Head: Front collection assembly designed to guide broilers onto the conveying system. Collection Conveyor Wings: Multiple conveyor sections create a broad harvesting area and direct birds toward the center of the machine. Transverse Conveyors: Transfer collected birds from the outer harvesting sections toward the central channel. Central Transfer Channel: Provides continuous controlled transportation toward the loading section. Caging Conveyor: Adjustable discharge conveyor transfers birds into crates, drawers or transport containers. Mobile Chassis: Supports movement inside poultry houses and repositioning during harvesting. Drive System: Powers machine movement and conveyor operation according to the selected configuration. Operator Controls: Allow adjustment of travel, conveyor operation and loading position. Weighing System: Optional or project-specific weighing equipment can control the quantity transferred into individual container sections. Container Handling Section: Can be integrated with a carousel, loading station or other transport module handling equipment.
Working Principle	The harvesting machine is positioned inside the broiler house and the front collection sections are opened to create the required working width. During operation, the machine advances progressively toward the flock while the collection conveyors operate at controlled speed. Broilers move onto the collection belts and are transferred toward transverse conveyors. These conveyors guide the birds into the central transfer channel without requiring workers to carry individual birds over long distances. The central conveyor transports the birds toward the caging area. An adjustable discharge conveyor then delivers them into the selected poultry transport crate, drawer or container. Where an automatic weighing system is specified, loading can stop or advance to the next compartment when the preset loading target is reached. Once a transport module has been completed, it can be removed from the loading position and transferred toward the poultry transport vehicle using compatible material handling equipment.
Technical Specifications	Product Type Automatic poultry harvesting and loading system Suitable Poultry Commercial broilers Harvesting Method Conveyor-assisted mechanical collection Harvesting Width Customizable according to poultry house dimensions Loading Capacity According to system configuration, bird weight and operating conditions Main Frame Galvanized steel and stainless steel components available according to configuration Mobility Tracked, wheeled or project-specific configuration Conveyor Speed Adjustable / according to project requirements Loading Conveyor Position Adjustable according to container configuration Automatic Weighing Available upon request Container Compatibility Designed according to local transport crate and container requirements Control System Manual-assisted or automatic control according to configuration Power System Available according to project requirements Cleaning Designed for routine washing and disinfection
Applications	Large commercial broiler farms Integrated poultry production complexes Mechanical broiler catching operations Automatic chicken loading projects Poultry transport container loading Multi-house broiler farms New steel structure poultry house projects Existing poultry farm modernization Poultry processing supply chain projects Livestock equipment engineering and turnkey poultry projects
Customization Options	Each poultry harvesting project can be configured according to flock size, poultry house dimensions, building entrances, internal columns, aisle width, transport container type and required harvesting workflow. Customization options may include harvesting head width, conveyor dimensions, belt configuration, mobile chassis design, loading height, automatic weighing, container handling arrangement, operator platform, controls and power configuration. The complete system can be designed according to local climate and farm conditions and coordinated with poultry feeding lines, drinking systems, ventilation equipment and steel structure building layouts.
Installation & Maintenance	Before delivery, the poultry house layout should be reviewed to confirm entrance dimensions, internal clearances, floor condition, equipment suspension height and the route between the harvesting area and transport vehicle. For mobile harvesting machines, installation is mainly focused on system preparation, operating adjustment and compatibility with the selected poultry containers rather than permanent anchoring to the building. Routine maintenance should include inspection of conveyor belts, rollers, bearings, hydraulic or mechanical drive components, tracks or wheels, fasteners, control devices and safety components. Conveyor tracking and tension should be checked periodically. After harvesting, surfaces that have been exposed to birds, litter and organic material should be thoroughly cleaned and disinfected according to the farm's biosecurity program. Easy access to service components helps reduce maintenance time between flock cycles.
Project Cases	Automatic poultry harvesting equipment is suitable for commercial broiler projects where manual catching requires large temporary labor teams or where farms need more standardized flock-loading procedures. In a typical ground-rearing poultry house, the mobile harvester travels through the production area while birds are conveyed toward transport modules positioned at the loading section. The modules are subsequently removed with compatible poultry handling or forklift equipment and transferred to the transport truck. For multi-house poultry farms, one mobile harvesting system can be planned to serve several buildings according to the farm's production and flock removal schedule.
Product FAQ	Q: What is an automatic poultry harvesting system? A: It is mechanized poultry equipment that collects broilers inside the poultry house and transfers them by conveyors toward crates or transport containers, reducing dependence on conventional manual catching. Q: Can the harvesting width be customized? A: Yes. The harvesting head and conveyor configuration can be designed according to poultry house width, internal obstructions and operating requirements. Q: Can it load different poultry transport containers? A: Yes. The loading section can be configured according to commonly used poultry crate, drawer and transport module systems. Container dimensions should be confirmed before production. Q: Can an automatic weighing system be supplied? A: Yes. Automatic weighing and preset loading control are available upon request depending on the selected system configuration. Q: Is the system suitable for an existing poultry house? A: In many projects it can be used in existing houses, provided entrance dimensions, internal clearances, floor conditions and suspended poultry equipment allow sufficient operating space. Q: What information is required for system design? A: Poultry house length and width, entrance dimensions, internal column arrangement, flock size, typical market weight, transport container dimensions, required loading method and local operating conditions are recommended.
Product Gallery
