Large-Span Double-Wheel Compost Turner

Published: 2026-09-28 Views: 0 Comments: 0 Source: SHEWUYOU Products Team Request a Quote
Product Showcase Content
Product Name Large-Span Double-Wheel Compost Turner
Product Image
large-span double-wheel compost turner for fermentation troughs
Product Overview The Large-Span Double-Wheel Compost Turner is designed for aerobic fermentation in wide, deep composting troughs. A steel bridge travels on rails alongside the fermentation area, while two powered turning wheels lift, loosen and mix the material. It is suited to centralized manure handling at commercial pig farms, livestock production facilities and organic fertilizer plants.
Key Features
  • Wide-span bridge layout serves a large fermentation area with fewer internal trough walls.
  • Two turning wheels break up compacted material and improve mixing and air contact.
  • Rail-guided travel supports repeatable turning along the composting bay.
  • Steel structure, drives and wear components can be specified for the operating environment.
  • Suitable for integration into a covered composting workshop or a larger farm waste treatment line.
Structural Components Typical assemblies include a spanning steel girder, twin turning wheels with paddles, wheel drive units, rail-travel mechanisms, power supply arrangement and electrical control cabinet. The final configuration is selected according to trough geometry, material characteristics and site layout.
Working Principle As the bridge moves along its rails, the rotating wheels engage the composting bed and lift and redistribute the material. Regular turning helps release trapped heat and moisture, blend pig manure with bulking materials such as straw or sawdust, and maintain conditions for aerobic decomposition. Turning frequency should be set according to the feedstock and composting process.
Technical Specifications
Working span and turning depth According to project requirements
Wheel and drive configuration Customizable
Power supply and controls Available upon request
Structural protection Designed according to local climate and farm conditions
Installation layout Matched to trough dimensions and rail alignment
Applications Pig manure composting, mixed livestock manure treatment, poultry litter processing, agricultural residue recycling and organic fertilizer production. Feedstock preparation and moisture management should be considered when designing the complete fermentation process.
Customization Options Bridge span, turning depth, wheel arrangement, electrical supply, control functions and surface protection can be reviewed for each project. SHEWUYOU can coordinate equipment dimensions with concrete troughs, rail supports, steel structure building clearances and material handling routes.
Installation & Maintenance Confirm trough dimensions, rail level and parallelism, foundation capacity, lifting access and electrical provisions before installation. Assemble and align the bridge and wheel units, then check travel and turning functions before loading material. Routine maintenance includes inspecting paddles, fasteners, bearings, drive components, rails and electrical connections.
Product FAQ

Can the turner be sized for an existing composting workshop?
Yes. Trough width, depth, rail position and available building clearance should be provided for a layout review.

Is it suitable for pig manure alone?
It can process pig manure, but suitable bulking material and moisture control may be needed to maintain an aerated composting bed.

What information is needed for a quotation?
Provide trough drawings, feedstock type, expected daily volume, site power supply and the required control arrangement.
Product Gallery

double-wheel compost turner installed in a covered fermentation workshop

large-span double-wheel compost turner operating concept

paddle wheel component for double-wheel compost turning equipment
