BTS-N40 Bovine Veterinary Ultrasound Scanner

• 8-inch display provides a large field-viewing area for farm diagnosis.
• Supports up to 16 pseudo-color display modes.
• 3.5MHz 128-element convex rectal probe designed for cattle reproductive imaging.
• Maximum listed detection depth of at least 160 mm.
• 256-level grayscale imaging for reproductive structure observation.
• Cine playback supports at least 400 frames.
• Dual rechargeable batteries extend field operating time.
• USB interface supports convenient image and data transfer.
• Sunshade and portable carrying case support outdoor veterinary work.

• Product Name: BTS-N40 Bovine Veterinary Ultrasound Scanner
• Model: BTS-N40
• Display Size: 8 Inches
• Pseudo-Color Display: Up to 16 Colors
• Probe Model: CXA60R
• Probe Type: 128-Element Convex Rectal Probe
• Probe Frequency: 3.5 MHz
• Maximum Detection Depth: At Least 160 mm
• Scanning Depth Adjustment: Approximately 70–240 mm
• Grayscale: 256 Levels
• Image Storage: 64 Frames
• Gain: 0–192 dB
• Gain Adjustment Range: 64–192 dB
• Cine Playback: At Least 400 Frames
• Focus Adjustment: Focus Number and Focus Position
• Image Processing: Pseudo Color, Grayscale Correction, Image Smoothing and Histogram
• Frequency Adjustment: 3 Levels
• Frame Correlation Adjustment: Supported
• Scanning Angle: Visually Adjustable
• Measurement Function: Backfat Measurement, Approximately ±1 mm
• Continuous Operating Time: More Than 3 Hours
• Dimensions: Approximately 278 × 165 × 38 mm
• Net Weight: Approximately 1380 g
• Power Consumption: Approximately 10 W
• External Interface: USB

The manufacturer describes the main unit as washable and suitable for demanding farm environments, but a specific IP protection rating is not listed. Avoid claiming a specific waterproof certification unless confirmed before ordering.

• Early cattle pregnancy examination.
• Dairy cow reproductive management.
• Beef cattle breeding programs.
• Uterine and ovarian structure observation.
• Follicle and corpus luteum imaging.
• Reproductive tract monitoring under veterinary guidance.
• Cattle breeding stations and artificial insemination programs.
• Mobile large-animal veterinary services.

• Fully charge both batteries before field operation.
• Inspect the probe, cable, connector and display before each examination.
• Use suitable veterinary ultrasound coupling gel.
• Ensure cattle are safely restrained before transrectal scanning.
• Clean and disinfect the rectal probe according to veterinary hygiene procedures after each animal.
• Avoid bending, crushing or pulling the probe cable excessively.
• Keep connectors clean and dry before reconnecting the probe.
• Use the sunshade when operating in strong outdoor light.
• Store the scanner, probe and accessories in the supplied protective carrying case.

Q: What is the BTS-N40 mainly used for?
A: It is designed primarily for cattle pregnancy examination and reproductive tract imaging in dairy and beef cattle operations.

Q: What type of probe is supplied?
A: The listed configuration includes a CXA60R 3.5MHz 128-element convex rectal probe.

Q: How large is the display?
A: The BTS-N40 uses an 8-inch display and supports up to 16 pseudo-color viewing modes.

Q: What is the listed maximum detection depth?
A: The manufacturer lists a maximum detection depth of at least 160 mm.

Q: Does the scanner support cine playback?
A: Yes. Cine playback is listed at 400 frames or more, with automatic image sequence storage and review functions.

Q: How long can the unit operate continuously?
A: The listed continuous operating time is more than three hours, and the standard configuration includes two rechargeable batteries.

Q: Can ultrasound images be exported?
A: Yes. The unit includes a USB interface for compatible storage and data-transfer applications.

Q: What is included in the standard package?
A: The listed package includes one main unit, one rectal probe, two batteries, one charger, one sunshade, coupling gel, one instruction manual and one protective carrying case.
