| Product Showcase | Content |
|---|---|
| Product Name | Stainless Steel Electric Auger Feed Cart |
| Product Image |
 Illustrative stainless steel electric feed cart shown: Weaverline reference model. Final SHEWUYOU configuration is subject to the approved specification. |
| Product Overview | The Stainless Steel Electric Auger Feed Cart is intended for mobile distribution of dry pig feed between storage or preparation points and feeding locations. A stainless steel feed hopper and motorized screw conveyor support controlled discharge into troughs or feeders. Its dimensions and outlet arrangement can be planned around pen fronts, door openings, aisle width, and turning space in commercial pig houses and steel structure farm buildings. |
| Key Features |
|
| Structural Components | A typical project configuration comprises a stainless steel hopper, supporting frame, auger and enclosed discharge tube, auger drive motor, outlet or chute, operator controls, running gear, and electrical protection. The selected wheel and steering arrangement depends on aisle geometry and floor conditions. Covers, guards, and service access are detailed during configuration. |
| Working Principle | Dry feed is loaded into the hopper and the cart is moved along the feeding route. At each discharge point, the operator starts the electric auger to convey feed through the outlet into a trough or feeder, then stops the auger before moving to the next pen. Delivered quantity depends on feed flow properties, auger configuration, and operating time; a verified weighing or automatic dosing function should be specified separately if required. |
| Technical Specifications |
|
| Applications | Suitable for planned feeding routes in sow, nursery, and grow-finish facilities where mobile feed delivery fits the operating procedure. It can serve new pig farm construction projects, steel structure pig houses, and retrofit sites where pen layout or phased operation makes a mobile cart practical. |
| Customization Options | Hopper volume, stainless steel grade, cart width, discharge orientation, outlet height, controls, wheel type, and charging arrangement can be reviewed against the feeding schedule and building drawings. Provide aisle width, door clearances, floor slope, trough height, feed characteristics, and available power when requesting a configuration. |
| Installation & Maintenance | The cart is a mobile unit; routine use does not require a fixed feed line to be installed along the pen row. Before commissioning, check travel clearance, charging provision, outlet alignment, guards, and control operation. Clean residual feed from the hopper and discharge path, inspect the auger and bearings, and maintain the battery and drive components according to the supplied equipment instructions. Isolate electrical power before opening guarded parts for service. |
| Product FAQ |
Can the cart discharge to either side? Is the cart suitable for wet feed? Is electric travel drive included? |
| Product Gallery |
 Related SHEWUYOU auger cart layout; the illustrated cart has a painted body.  Related SHEWUYOU stainless steel cart construction; final auger cart appearance depends on the selected configuration. |
