Product Name	Double Cattle Magnet Applicator
Product Image
Product Overview	Double Cattle Magnet Applicator is a professional livestock administration tool designed for efficient placement of ruminal magnets or compatible veterinary boluses in cattle. The double-capacity configuration allows two magnets or two boluses to be introduced during one administration procedure, helping improve workflow efficiency in commercial cattle operations. The reference configuration uses a stainless-steel body combined with an aluminum handle for secure handling. Its elongated applicator tube and mechanical delivery system provide controlled administration for veterinary clinics, dairy farms, beef cattle operations, breeding centers, and livestock health programs.
Key Features	• Double-capacity design allows administration of two compatible ruminal magnets or two boluses at the same time. • Stainless-steel applicator structure provides durability and corrosion resistance for livestock environments. • Aluminum handle provides a secure grip during cattle handling and administration. • Long applicator shaft supports controlled positioning during oral administration. • Mechanical delivery system requires no electrical or pneumatic power. • Reusable construction is suitable for commercial cattle farms and professional veterinary operations. • Applicator configuration and packaging can be supplied according to project requirements.
Structural Components	The Double Cattle Magnet Applicator generally consists of a stainless-steel applicator shaft, cylindrical loading head, internal delivery rod, operating linkage, aluminum handle, and mechanical release mechanism. The loading head is designed to accommodate compatible cattle magnets or boluses, while the push mechanism transfers the loaded products from the applicator into the animal's oral passage during professional administration.
Working Principle / Structural Principle	Two compatible magnets or boluses are loaded into the applicator head before use. After the animal is properly restrained, the applicator is carefully introduced through the mouth by trained personnel and positioned for administration. Operating the handle advances the internal push rod, releasing the loaded magnets or boluses. The applicator is then withdrawn carefully after successful delivery. Proper cattle restraint and correct swallowing position are essential during use.
Technical Specifications	Product Type: Double Cattle Magnet Applicator / Multi Bolus Gun Application: Administration of ruminal magnets and compatible cattle boluses Capacity: Two magnets or two boluses per administration cycle Main Body Material: Stainless steel Handle Material: Aluminum Overall Length: Approximately 46 cm Head Diameter: Approximately 25 mm Head Length: Approximately 75 mm Operation: Manual mechanical delivery Power Requirement: None Other Configurations: Available upon request
Applications	Double Cattle Magnet Applicator is designed for professional oral administration of ruminal magnets and compatible veterinary boluses to cattle. Ruminal magnets are commonly used in cattle management to collect ferromagnetic foreign objects that may be swallowed with feed, helping reduce the risk associated with sharp metallic material in the reticulum. The applicator can also support compatible bolus administration according to veterinary and herd-management requirements. Typical application environments include dairy farms, beef cattle farms, livestock breeding centers, veterinary clinics, feedlots, agricultural cooperatives, and large-scale cattle health programs.
Customization Options	SHEWUYOU can provide applicator configurations according to different cattle management and project requirements. Options may include applicator length, loading-head dimensions, handle configuration, compatible magnet or bolus specifications, packaging methods, and bulk purchasing quantities. OEM and project supply solutions are available for livestock equipment distributors, cattle groups, veterinary suppliers, agricultural engineering companies, and international purchasers.
Installation & Maintenance	No fixed installation is required. Before each use, inspect the applicator tube, loading head, handle, push rod, and moving components to confirm that they operate smoothly and are free from deformation or damage. After use, remove residue from the applicator, clean all surfaces thoroughly, and process reusable components according to applicable veterinary hygiene procedures. Dry the instrument completely before storage and keep moving parts clean for reliable operation.
Project Cases	Suitable for commercial dairy farms, beef cattle operations, cattle breeding centers, feedlots, veterinary service organizations, livestock health management programs, agricultural cooperatives, and veterinary equipment distribution projects requiring efficient magnet or bolus administration equipment.
Product FAQ	Q: Why is it called a Double Cattle Magnet Applicator? A: The reference multi-bolus configuration is designed to introduce two compatible magnets or two boluses at the same time. Q: What is the applicator made from? A: The reference configuration uses a stainless-steel applicator body with an aluminum handle for secure handling. Q: What is the standard applicator length? A: The referenced configuration has an overall length of approximately 46 cm, with a head diameter of approximately 25 mm and a head length of approximately 75 mm. Q: Does the applicator require electricity? A: No. It uses a manual mechanical delivery system. Q: Can it also administer cattle boluses? A: Yes. The reference design is intended for compatible ruminal magnets as well as compatible cattle boluses. Q: Can specifications be customized? A: Yes. Applicator dimensions, loading configurations, packaging, and bulk supply options can be provided according to project requirements.
Product Gallery
